HOME > Shopping > Defiant
Mouse over to zoom in
Defiant
USD
( 0 Points required )
Editions
Standard Edition
Please select a Editions
Quantity
piece (999 pieces available)
0 pieces available
Product Details
Specifications
Warranty & Returns
FAQ
Reviews






Model:                                         Defiant

-------------------------------------------------------------------------------------------------------------------------------------------------------------


Connector Complement:                2×3 pin XLR female jack for Balance Input

                                                       1×4.4mm female jack for Balance Input

                                                       1×4 pin XLR female jack for Balance Output

                                                       1×4.4mm female jack for Balance Output

                                                       1×DC005 power jack for charge or DC adapter

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Frequency Response:                  20Hz-20KHz,±0.15dB

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maximum Voltage Input:            0.14A

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maximum Current Output:          0.5A(balance)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maximum Voltage Output:          15V RMS(balance)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maximum Power Output,32ohm  :    6.5W RMS per channel(balance)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maximum Power Output,300ohm:     750mW RMS per channel(balance)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maximum Power Output,600ohm:     375mW RMS per channel(balance)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

THD:                              ≤0.013%,20Hz-20KHz,1V RMS

-------------------------------------------------------------------------------------------------------------------------------------------------------------

IMD:                              ≤0.025%,1V RMS

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SNR:                              ≥105dB,1V RMS,unweighted,gain=12.7dB

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Crosstalk:                       ≥98dB,20Hz-20KHz

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Output Impedance:       0.25ohm

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Gain:                               4.3(12.7dB)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Topology:                         Preamp+Voltage Gain+Current Buf,

                                           dual mono,precision virtual ground

                                           reference,isolated power supply

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Power Supply:                  25V battery(inside)or 18V DC adapter

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Power Consumption:       0.2W

------------------------------------------------------------------------------------------------------------------------------------------------------------

Size:                                 155×135×50(mm,MAX)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Weight:                            1300g(standard edition),2900g(gold edition)
