HOME > Shopping > Enterprise E Lite
Mouse over to zoom in
Enterprise E Lite
USD
( 0 Points required )
Editions
Standard Edition
Please select a Editions
Quantity
piece (999 pieces available)
0 pieces available
Product Details
Specifications
Warranty & Returns
FAQ
Reviews


Model :Enterprise E Lite

Connector Complement :

2×XLR for Input

1×STAX PRO jack for Output

Frequency Response   :20Hz-20KHz,-0.2dB

Maximum Current Output :0.007A

Maximum Voltage Output :325V RMS(1KHz)

Maximum Power Output,for STAX 009 :4.05mA 325V RMS per channel(20K Hz)

Maximum Power Output,for STAX 007MKII :3.46mA 325V RMS per channel(20K Hz)

THD :≤0.01%,(100V RMS,1KHz)

IMD :≤0.01%

SNR :≥112dB,100V RMS,1KHz,unweighted

Crosstalk :≥98dB,20Hz-20KHz

Gain :57dB

Bias :580V

Topology :BJT Folded Cascode+Tube with CCS

Vacuum Tube :6SN7GTB*2

Power Supply :230V/115V 50-60Hz

Power Consumption :150W MAX

Size :370*220*140(L*W*H,mm)

Weight :9kg(only amp)
