3 Information on Prime DAC

"A-Weighted noise/μV (low is better)

Ranking from top to bottom

Prime DAC 1.68 $ 99.8

iBasso DX300 3.2 $1199

LP P6P 1.78 $3,899

Dual Mono ES9018k2m

opa1656x7

3w(600mA @5V typical)

con

limited to 24bit 96khz

humble looking for its price-tag (a megatron with a different faceplate, basically, copper version is of course , better looking , basically a mini DF se)

though it works OOB(out of the box, no driver needed even) with your PC, you do need to use a PowerBank or with external PD power to work with a phone (so if your phone can do play & charge with megatron , then you are good , on the go)

Pro

500usd tier desktop dac level sound with flagship portable level noise control

no aggressive filter to kill the musicality for SPEC

Ultra-low noise floor

same TXCO

A-Weighted noise/μV (low is better)

Ranking from top to bottom

Prime DAC 1.68 $ 99.8

iBasso DX300 3.2 $1199

LP P6P 1.78 $3,899

this is measured with normal usb-c cable/

no external linear power supply unit~

just straight with the PC usb port~

We got a better Lineout

with WAY better sound ....again the goal was to be comparable to mid-upper tier desktop DAC( 500USD+ )

yet even slightly less noise~

there is NO magic here~

just good old proper design and not going cheap with the

power consumption~

There is no DAP that can be ok with 3w without power consumption~

yeah and I have tested them with our Defiant Gold Edition ~

and Enterprise 12th~

it is safe to say~ we nailed it~

Cheers

Lee

p.s. (photo is defiant gold / enterprise 12th(prototype) / Prime DAC)"
