Model：Defiant SE
Connector Complement：
1×3.5mm TRS jack for Signal Input
1×4.4mm TRRRS jack for Earphone Output
1×3.5mm TRS jack for Earphone Output
1×DC5.5/2.1 power jack for DC in
Frequency Response：20Hz-20KHz，±0.05dB
Maximum Current Output：0.25A
Maximum Voltage Output：5V RMS
Maximum Power Output，32ohm：780mW RMS per channel
Maximum Power Output，300ohm：83mW RMS per channel
Maximum Power Output，600ohm：40mW RMS per channel
THD：≤0.015%，20Hz-20KHz，2V RMS
IMD：≤0.0003%，2V RMS
SNR：≥106dB，2V RMS，A-weighted，gain=10dB
Crosstalk：≥95dB，20Hz-20KHz
Gain：10（6dB）
Topology：INA Pre-Gain，Dual mono，
Precision virtual ground reference，Isolated power supply
Power Supply：16.8V BAT or <18V DC adapter
Power Consumption：0.2W
